4601-01 COM Reader
The 4601-01 COM Reader combines contemporary styling with proven optical performance, making it a reliable choice for high-volume microform viewing. With full 100 percent blow-back and a precision optical system, it produces a sharp, high-resolution image that is comfortable to read for extended periods.
Built for day-to-day use, this reader supports a wide range of formats, including COM fiche and jacketed film. Its lightweight construction, removable components, and front-mounted controls make operation simple while keeping maintenance straightforward.
Micrographic Engineering Services is an authorised dealer of Indus scanners in Australia.
4601-01 COM Reader
Key Features
High-Resolution Optical Performance
Precision optics and full 100 percent blow-back deliver a sharp, easy-to-read image across all supported formats.
Wide Format Compatibility
Accommodates COM fiche, standard microfiche, jacketed film, and aperture cards for versatile document viewing.
Optional Dual Lens System
Switch between magnifications using a precise lever-operated dual lens setup, allowing quick changes without interrupting work.
Large Angled Viewing Screen
Rear-projection, non-glare screen improves readability and reduces eye strain during extended use.
Smooth Precision Carrier
Self-opening carrier provides stable, controlled film movement for accurate positioning and comfortable operation.
Service-Friendly Construction
Removable screen, bezel, and power drawer simplify cleaning, lens changes, and routine maintenance.
Lightweight, Durable Build
High-impact plastic construction keeps the unit robust while remaining easy to move and reposition.
What’s Included
- 4601-01 COM Reader unit
- Standard self-opening fiche carrier
- Precision optical lens system (single lens as standard)
- Rear-projection non-glare viewing screen
- Dual Intensify lamp system
- Five-year limited manufacturer warranty
Why Choose the 4601-01 COM Reader
- Built for reliable, everyday microform viewing
- Produces clear, high-resolution images without digital complexity
- Simple mechanical operation with minimal user training
- Supports COM fiche, jacketed film, and aperture cards
- Easy to maintain with removable screen and power drawer
- Backed by Micrographic Engineering Services support and expertise
Specifications
- Viewing System: Precision optical system with full 100 percent blow-back for clear, high-resolution images.
- Magnification: Optical options of 21x, 24x, 32x, 36x, 42x, 48x, 54x, with optional 72x.
- Screen: Rear-projection, non-glare display measuring 360 mm x 282 mm, available in blue, grey, or green.
- Carrier System: Standard 105 mm x 152 mm self-opening carrier, with optional larger or dual configurations.
- Supported Media: COM fiche, microfiche, jacketed film, and aperture cards.
- Focus Control: Front-mounted precision focus control for accurate image adjustment.
- Illumination: Dual Intensify lamp system rated at 13.8V, 30W.
- Construction: High-impact plastic housing for durability with reduced overall weight.
- Dimensions & Weight: 400 mm (W) x 530 mm (H) x 495 mm (D), total weight 6.8 kg.
- Warranty: Five-year limited manufacturer warranty
Request a Quote for 4601-01 COM Reader
Get the 4601-01 COM Reader Today
View COM fiche and microform records with clear, high-resolution optical performance using the 4601-01 COM Reader.
Order now or contact Micrographic Engineering Services for practical advice before you buy.
