4601-11 A4 Screen Reader
The 4601-11 A4 Screen Reader is a versatile microform reader built for full-size viewing of source documents from 16 mm and 35 mm rollfilm, with full blow-back for source documents and three-quarter blow-back for COM. Its A4 rear-projection screen, combined with precision optics, delivers clear, stable images suited to detailed reference work.
This reader includes standard 360-degree image rotation, allowing documents to be viewed in any orientation using a single lens or dual lens configuration. Centralised front-mounted controls for focus and image rotation support smooth, accurate adjustment, while the works-in-a-drawer design and long-life dual intensity lamp make day-to-day operation practical and dependable.
Micrographic Engineering Services is an authorised dealer of Indus scanners in Australia.
4601-11 A4 Screen Reader
Key Features
A4 Rear-Projection Viewing
A4-sized rear-projection screen supports full-size viewing of source documents with reduced glare and improved readability.
Full and Partial Blow-Back Support
Full blow-back for 16 mm and 35 mm source documents, with three-quarter blow-back for COM viewing.
360-Degree Image Rotation
Standard image rotation allows documents to be viewed in any orientation using single or dual lens configurations.
Wide Media Compatibility
Supports microfiche, jacketed fiche, and 16 mm and 35 mm rollfilm on open reels.
Precision Optical System
High-quality optics provide consistent clarity across multiple magnification options.
Flexible Carrier Options
Compatible with manual and motorised rollfilm carriers, as well as fiche carriers.
Portable Configuration
Optional carrying handle allows easier transport between workspaces.
What’s Included
- 4601-11 A4 Screen Reader unit
- Rear-projection A4 viewing screen
- Standard fiche carrier, 105 mm x 152 mm self-opening
- Manual 16 mm and 35 mm rollfilm carrier for open reels
- Dual Intensify lamp system
- One-year limited manufacturer warranty
Why Choose the 4601-11 A4 Screen Reader
- Ideal for viewing source documents at full size
- Handles both fiche and rollfilm formats with ease
- Image rotation simplifies viewing of misaligned or rotated records
- Front-mounted controls support precise adjustment with minimal training
- Suitable for archives, libraries, engineering offices, and technical environments
- Backed by Micrographic Engineering Services support and expertise
Specifications
- Viewing System: Precision optical system with rear-projection A4 screen and full or partial blow-back depending on media type.
- Magnification: Standard single lens options of 24x, 32x, 36x, 42x, and 48x. Optional dual lens system with additional 18x and 15x options.
- Screen: Rear-projection screen measuring 294.6 mm x 284.4 mm, standard non-glare blue, optional grey or green.
- Carrier System: 105 mm x 152 mm self-opening fiche carrier and 16 mm and 35 mm manual rollfilm carrier for open reels.
- Supported Media: Microfiche, jackets, and 16 mm and 35 mm rollfilm on open reels.
- Image Rotation: Standard single prism 360-degree rotation, optional dual prism for dual lens systems with 18x and 15x.
- Indexing: Interchangeable grid system for fiche.
- Focus and Rotation Control: Front-mounted, gear-driven precision control.
- Illumination: Dual Intensify lamp system rated at 13.8V, 50W.
- Construction: Metal and high-impact plastic housing.
- Dimensions and Weight: 298.4 mm (W) x 577.8 mm (H) x 406.4 mm (D), total weight 12.7 kg.
- Power Requirements: Standard 120V, 50/60Hz, optional 220V to 240V, 50/60Hz, CE marked.
- Warranty: One-year limited manufacturer warranty.
Request a Quote for 4601-11 A4 Screen Reader
Get the 4601-11 A4 Screen Reader
Built for archives and technical environments, the 4601-11 A4 Screen Reader supports both fiche and rollfilm with consistent optical clarity.
Contact Micrographic Engineering Services to confirm configuration options or availability.
