Contactless Scanner EPIC 4870
The SMA EPIC 4870 Contactless Scanner represents a breakthrough in non-contact digitisation technology. Designed for institutions and industries that require delicate handling, this advanced system scans face-up originals without using a glass plate.
Powered by V3D (Visual 3D) technology, the EPIC 4870 captures structured and reflective materials, from wood, textiles, and rubber to coins, seals, and metallic prints, with stunning depth and precision. Its bidirectional scanning system, fast operation, and IR/UV-free LED illumination make it ideal for archival, museum, and industrial applications.
Micrographic Engineering Services is an authorised dealer of SMA scanners in Australia.
Contactless Scanner EPIC 4870
Key Features
Contactless, Face-Up Scanning
Digitises documents and objects without physical contact, preserving fragile or valuable originals.
V3D Technology (Visual 3D)
Captures intricate surface details and textures using multiple lighting intensities, delivering lifelike, high-depth images.
High Optical Resolution
Achieves a true optical resolution of up to 600 ppi across the full scanning range for superior clarity.
Laser-Guided Focus System
Automatically positions the optical unit for perfect focus using a precision laser grid and light barrier system.
Fast, Bidirectional Operation
Reduces scan time and mechanical strain by scanning in both directions, increasing overall productivity.
Safe, UV- and IR-Free LED Illumination
Ensures consistent, harmless lighting suitable for sensitive materials such as manuscripts, textiles, and artworks.
What’s Included
- V3D (Visual 3D) scanning technology
- Removable, wheeled object table for easy handling of bulky originals
- Integrated LED light system with IR/UV-free illumination
- Built-in IP interface with dedicated device address
- Automated laser-guided positioning and scanning control
Why Choose the EPIC 4870
- Contact-free scanning for ultimate preservation of delicate materials.
- Captures textured and reflective surfaces with exceptional 3D accuracy.
- Advanced German-engineered scan engine for high-definition output.
- Fully automated operation with bidirectional scanning for efficiency.
- Trusted worldwide by museums, archives, and research institutions.
Specifications
- Scanning Technology: Contactless CCD line sensor system, fully sealed and dust-proof, with V3D (Visual 3D) technology for precise surface capture; optical resolution up to 600 ppi.
- Scanning Range: 1219 × 1778 mm (48 × 70 in), suitable for 2A0 and oversized originals.
- Scan Modes & Speed: Colour, greyscale, and bitonal modes; full-range scanning in 2D mode takes approximately 18 seconds at 300 dpi or 36 seconds at 600 dpi, while V3D mode completes scans in 36 seconds at 300 dpi or 72 seconds at 600 dpi.
- Colour Depth: 48-bit capture with 24-bit output for colour, and 16-/8-bit output for greyscale imaging.
- Lighting System: White LED illumination, IEC 60825-1 Class 1 certified, IR- and UV-free for safe and consistent operation.
- Connectivity: GBit network and USB 3.0 interfaces for high-speed data transfer.
- Inbuilt PC: Linux operating system, Intel i3 Quad Core processor, 8 GB RAM, and 320 GB HDD for integrated scanning control.
- Software: Batch Scan Wizard included, with advanced imaging and automation features.
- Object Handling: Fully removable plug-and-play table for flexible positioning of large or heavy originals.
- Power & Environment: Operates between +5°C and +40°C, humidity 20–80% (non-condensed).
- Dimensions & Weight: Width 230 cm, depth 145 cm, height adjustable from 106–165 cm; weight approximately 300 kg.
- Operating Systems: Compatible with Windows 10 (64-bit) and Linux.
Request a Quote for Contactless Scanner EPIC 4870
Order the EPIC 4870 Today
Experience next-generation contactless digitisation with the SMA EPIC 4870.
Order now or contact Micrographic Engineering Services for expert advice on selecting the right scanner for your scanning environment.
