Contex HD Ultra X 4290
Precision meets performance in the Contex HD Ultra X 4290, a 42-inch large format scanner built for high-output environments that demand both speed and image excellence. With an upgraded CCD system, 48-bit colour capture, and true 1200 dpi optical resolution, the 4290 model provides unmatched detail across maps, drawings, and artworks.
The HD Ultra X 4290 is also available in a PRO version. It boasts the same high-speed scanning performance with a few professional-grade enhancements. The PRO package includes a full Nextimage Repro software licence, an optional 22-inch multi-touch display, and a low-stand configuration for integrated workstation setups. Designed for high-volume CAD, GIS, and reprographic workflows, the PRO variant delivers a complete scanning solution ready for production environments.
Micrographic Engineering Services is an authorised dealer of Contex scanners in Australia.
Contex HD Ultra X 4290
Model Version
Available Models:
- HD Ultra X 4290 ScanStation (Standard)
- HD Ultra X 4290 ScanStation Pro
Key Features
High-Speed Throughput
Reaches scanning speeds up to 17.8 inches per second in RGB colour, enabling rapid capture of large-format documents without image degradation.
42-Inch Scanning Width
Accommodates originals up to 43.3 inches wide and 15 mm thick, making it ideal for technical drawings, posters, and mounted materials.
Enhanced CCD Technology
Equipped with five advanced 4-linear CCD sensors delivering 213,600 total pixels for impeccable clarity, colour accuracy, and geometric precision.
Adaptive Colour Space Management
Supports Adobe RGB, Device RGB, RAW RGB, and sRGB workflows with ICC colour control via Nextimage 7 and X-Rite® profiling.
True Size Detection
Automatically detects document width and alignment, removing manual setup steps and reducing the risk of cropping or skewing.
Energy Star 3.0 Certified
Optimised LED illumination and reduced maintenance requirements lower total ownership costs while maintaining consistent image quality.
What’s Included
- Contex HD Ultra X 4290 large format scanner
- Power and data cables
- Calibration sheet and cleaning accessories
- Nextimage free trial software (with TWAIN driver)
- Quick-start and installation guide
- PRO variant includes a full Nextimage Repro licence, 22-inch touchscreen interface, and low-stand configuration for production use.
Why Choose the Contex HD Ultra X 4290
- 42-inch format with industry-leading CCD optics for uncompromised detail.
- Batch productivity of up to 875 documents per hour at 200 dpi.
- Upgradable colour speed and connectivity flexibility via USB 3.0 and Gigabit Ethernet.
- Optional Nextimage Remote app for wireless tablet control (iOS and Android).
- Built in Denmark with premium materials and scratch-resistant glass for long-term reliability.
HD Ultra X 4290 Standard Specifications
- Scanning Technology: Utilises 5 × 4 linear colour CCD sensors (RGB and greyscale) with 213,600 total pixels, delivering precision imaging across the full 42-inch scan width.
- Optical Resolution: 1200 dpi native optical resolution, expandable up to 9600 dpi through interpolation for exceptional clarity and fine line accuracy.
- Maximum Scan and Media Width: Supports originals up to 42 inches (1067 mm) with a total media width of 43.3 inches (1100 mm), ideal for large-scale maps, drawings, and posters.
- Media Thickness and Focus Depth: Handles materials up to 0.6 inches (15 mm) thick with a depth of focus of 0.3 inches (7 mm), enabling accurate scanning of mounted or uneven surfaces.
- Scanning Speed: Delivers up to 17.8 inches per second in RGB colour at 200 dpi and the same in grayscale/monochrome mode for rapid batch processing.
- Productivity Rate: Capable of scanning up to 875 Arch E-size (portrait) documents per hour in RGB colour at 200 dpi for high-volume environments.
- Colour Management: Supports Adobe RGB, Device RGB, RAW RGB, and sRGB colour spaces, fully compatible with Nextimage 7 software and X-Rite® ICC profiling for FADGI 3-star compliance.
- Connectivity Options: Features USB 3.0 with xDTR3 and Gigabit Ethernet with xDTR2.5 interfaces for high-speed data transfer and network integration.
- File Output Formats: Outputs to TIF, JPG, PDF, PDF/A, DWF, CALS, BMP, JPEG-2000 (JP2/JPX), and multi-page PDF formats for flexible document management.
- Software Compatibility: Ships with a Nextimage free trial (including TWAIN driver). Optional upgrades include Nextimage Scan & Archive, Nextimage Repro, and the Nextimage Remote tablet app for iOS and Android.
- Dimensions and Weight: 1360 × 540 × 279 mm (53.6 × 21 × 11 in) with a total weight of 49.3 kg (109 lbs). Optional scanner stand available in 922 / 947 / 972 mm height configurations.
- Power and Certifications: ENERGY STAR® certified and compliant with RoHS, REACH, cUL, CE, CCC, VCCI, and Customs Union standards for efficiency and environmental responsibility.
HD Ultra X 4290 Pro Version Enhancements:
- Full Nextimage Repro software licence included
- Optional 22-inch multi-touch monitor (1920 × 1080) with VESA mounting
- Low-stand configuration for integrated workstation setups
- Explicit AutoCAD, MicroStation, and ArcGIS compatibility
- Built-in power supply (100 V – 240 V, 39 W ready / <1 W sleep / 130 W scan)
Request a Quote for Contex HD Ultra X 4290
Order the HD Ultra X 4290 Today
Add professional-grade precision to your workflow with the Contex HD Ultra X 4290. Order online today, or contact our team for expert advice on the best model for your scanning needs.
