Contex HD Ultra X 6050
The Contex HD Ultra X 6050 is a professional 60-inch large format scanner built for precision, colour accuracy, and consistent results across oversized documents. As part of the 60-inch class within the HD Ultra X series, the 6050 offers the same expansive width as the 6090 but is optimised for environments where consistent, dependable performance is prioritised over maximum speed.
The HD Ultra X 6050 is also available in a PRO variant, which offers the same 60-inch scanning hardware with enhanced professional functionality. The PRO version includes a full Nextimage Repro software licence, an optional 22-inch multi-touch display, a low-stand configuration, and an upgradeable colour-speed mode for faster throughput. This makes it ideal for reprographic studios, CAD/GIS offices, and production-scale scanning environments.
Micrographic Engineering Services is an authorised dealer of Contex scanners in Australia.
Contex HD Ultra X 6050
Model Version
Available Models:
- HD Ultra X 6050 ScanStation (Standard)
- HD Ultra X 6050 ScanStation Pro
Key Features
60-Inch Scan Width
Handles documents up to 61.8 inches wide, perfect for wide-format CAD plans, GIS maps, posters, and art reproductions.
Seven CCD Sensor Array
Fitted with seven 4-linear CCDs (RGB and greyscale), totalling 299,040 pixels for high-fidelity image capture and smooth tonal gradients.
Precision Optical System
Delivers true 1200 dpi optical resolution, expandable to 9600 dpi for intricate, detail-rich imaging.
Reliable Scanning Speed
Provides up to 8.9 inches per second in RGB colour and 17.8 inches per second in monochrome, balancing precision with productivity. (PRO variant includes upgradeable colour speed up to 17.8 ips.)
Consistent Colour Accuracy
Supports Adobe RGB, Device RGB, RAW RGB, and sRGB colour spaces, with ICC calibration through Nextimage 7 and X-Rite® profiling.
Energy-Efficient and Durable
Energy Star 3.0 certified with long-life LED lighting that requires no replacement and minimises heat and maintenance costs.
What’s Included
- Contex HD Ultra X 6050 large format scanner
- Built-in touchscreen interface
- Power and data cables
- Calibration and cleaning accessories
- Nextimage free trial software (with TWAIN driver)
- PRO variant includes a full Nextimage Repro licence, 22-inch touchscreen interface, low-stand configuration, and upgradeable colour speed.
Why Choose the Contex HD Ultra X 6050
- 60-inch wide scanner optimised for high-precision, full-width scanning.
- Seven-sensor CCD design for excellent image uniformity and clarity.
- Handles mounted or thick originals up to 15 mm with reliable focus depth.
- Non-upgradable colour speed configuration for consistent performance and stability. (PRO variant offers upgradeable colour speed.)
- Meets ENERGY STAR®, RoHS, and CE standards for professional reliability and efficiency.
HD Ultra X 6050 Standard Specifications
- Scanning Technology: 7 × 4 linear CCD sensors (RGB and greyscale) with 299,040 total pixels, providing superior image detail and colour accuracy across the entire scan width.
- Optical Resolution: 1200 dpi native optical resolution, expandable to 9600 dpi via interpolation for precise line and texture reproduction.
- Maximum Scan Width: 60 inches (1524 mm) with total media width of 61.8 inches (1570 mm), accommodating oversized drawings, maps, and banners.
- Media Thickness & Focus Depth: Supports materials up to 0.6 inches (15 mm) thick with a 0.3-inch (7 mm) focus depth, suitable for rigid or mounted originals.
- Accuracy: Maintains geometric precision at 0.1% ± 1 pixel, ensuring consistent reproduction of large-format technical and artistic documents.
- Scanning Speed: Achieves up to 8.9 inches per second in RGB colour and 17.8 inches per second in grayscale or monochrome at 200 dpi.
- Productivity Rate: Capable of scanning up to 519 Arch E-size (portrait) colour documents per hour at 200 dpi, optimised for continuous operation.
- Colour Space: Supports Adobe RGB, Device RGB, RAW RGB, and sRGB colour modes for professional imaging workflows.
- File Formats: Exports to TIF, JPG, PDF, PDF/A, DWF, CALS, BMP, JPEG-2000 (JP2, JPX), and multi-page PDF formats.
- Connectivity: USB 3.0 with xDTR3 and Gigabit Ethernet with xDTR2.5 interfaces for high-speed data transfer and networked operation.
- Software Compatibility: Includes Nextimage free trial (with TWAIN driver); optional software includes Nextimage Scan & Archive, Nextimage Repro, and the Nextimage Remote app for iOS and Android.
- Dimensions & Weight: 1810 × 540 × 279 mm (71 × 21 × 11 in); 62 kg (137 lbs). Optional stand heights available at 922, 947, or 972 mm.
- Operating Systems: Compatible with Windows 10 and 11 (64-bit) and Windows Server 2022 Standard Edition.
- Certifications: ENERGY STAR®, RoHS, REACH, cUL, CE, CCC, VCCI, and Customs Union certified for environmental and safety compliance.
HD Ultra X 6050 Pro Version Enhancements
- Upgradeable colour scanning speed (8.9 → 17.8 inches per second at 200 dpi)
- Full Nextimage Repro software licence included
- Optional 22-inch multi-touch monitor (1920 × 1080) with VESA mounting
- Low-stand configuration for integrated workstation setups
- Explicit AutoCAD, MicroStation, and ArcGIS compatibility
- Built-in power supply (100 – 240 V, 39 W ready / <1 W sleep / 130 W scan)
Request a Quote for Contex HD Ultra X 6050
Order the HD Ultra X 6050 Today
Digitise your large-format documents with the professional-grade Contex HD Ultra X 6050. Order today, or get in touch for expert guidance on choosing the ideal model for your scanning workflow.
