Contex HD Ultra X 6090
The Contex HD Ultra X 6090 is the high-performance model in the 60-inch class of the HD Ultra X series, delivering top-tier speed, image precision, and productivity. With its seven-sensor CCD array, 48-bit colour processing, and upgradable colour speed configuration, the 6090 is engineered for demanding environments where throughput and accuracy are equally critical.
The HD Ultra X 6090 is also available in a PRO variant, which combines the same advanced scanning system with a complete production-ready setup. The PRO version includes a full Nextimage Repro software licence, an optional 22-inch multi-touch display, and a low-stand workstation configuration. It’s designed for reprographic studios, CAD and GIS teams, and professional environments requiring high-volume, integrated workflows.
The PRO variant includes the same high-precision scanning engine but ships with the full colour-speed capability unlocked (17.8 ips at 200 dpi in RGB) and a full Nextimage Repro licence, making it ready for production workflows right out of the box.
Micrographic Engineering Services is an authorised dealer of Contex scanners in Australia.
Contex HD Ultra X 6090
Model Version
Available Models:
- HD Ultra X 6090 ScanStation (Standard)
- HD Ultra X 6090 ScanStation Pro
Key Features
60-Inch Scan Width
Handles documents up to 61.8 inches wide—ideal for oversized technical drawings, artwork, GIS maps, and photographic reproductions.
Seven CCD Sensor System
Features seven 4-linear CCDs (RGB and greyscale) with 299,040 total pixels, capturing ultra-fine detail with remarkable tonal consistency.
Upgradable Colour Speed Configuration
The HD Ultra X 6090 includes an upgradable colour speed mode for enhanced throughput, delivering professional-grade productivity for high-demand workflows. (Included as standard in the PRO configuration.)
Exceptional Throughput
Scans at 17.8 inches per second in RGB colour and monochrome at 200 dpi, processing up to 875 Arch E-size pages per hour.
Precision and Accuracy
Maintains 0.1% ± 1 pixel accuracy, ensuring technical and artistic originals are digitised with true-to-scale precision.
Advanced Colour Management
Supports Adobe RGB, Device RGB, RAW RGB, and sRGB colour profiles, fully compatible with Nextimage 7 and X-Rite® ICC calibration tools.
Energy Star 3.0 Certified
Equipped with efficient LED lighting for lower energy use, reduced heat, and minimal maintenance, extending long-term scanner life.
What’s Included
- Contex HD Ultra X 6050 large format scanner
- Built-in touchscreen interface
- Power and data cables
- Calibration and cleaning accessories
- Nextimage free trial software (with TWAIN driver)
- Pro version includes a full Nextimage Repro licence, 22-inch touchscreen interface, low-stand configuration, and integrated workstation compatibility.
Why Choose the Contex HD Ultra X 6090
- Fastest 60-inch model in the HD Ultra X series for production-level workflows.
- Upgradable colour speed setting for increased productivity when required.
- Delivers 48-bit colour fidelity and 1200 dpi optical resolution for superior imaging.
- Handles thick or mounted media up to 15 mm with consistent accuracy.
- Meets ENERGY STAR®, RoHS, and CE standards for professional efficiency and environmental performance.
- PRO version adds touchscreen operation, Nextimage Repro software, and low-stand production setup for advanced integration.
HD Ultra X 6090 (Standard) Specifications
- Technology: 7 × 4 linear CCD sensors (RGB and greyscale) with 299,040 total pixels for ultra-precise image capture and tonal depth.
- Optical Resolution: True 1200 dpi optical resolution; up to 9600 dpi interpolated for detailed line and texture reproduction.
- Maximum Scan Width: 60 inches (1524 mm); total media width 61.8 inches (1570 mm) for large-format projects.
- Maximum Media Thickness: Supports originals up to 0.6 inches (15 mm) thick; 0.3-inch (7 mm) depth of focus for mounted or uneven materials.
- Accuracy: ±0.1% + 1 pixel for geometrically accurate scans of technical and creative documents.
- Productivity: Capable of scanning up to 875 Arch E-size colour pages per hour at 200 dpi, ideal for production environments.
- Scanning Speed: 17.8 ips in RGB colour, greyscale, and monochrome at 200 dpi.
- Upgradable Colour Speed: Yes, allowing enhanced throughput for high-volume operations.
- Colour Space: Adobe RGB, Device RGB, RAW RGB, sRGB for full-spectrum colour management.
- File Formats: TIF, JPG, PDF, PDF/A, DWF, CALS, BMP, JPEG-2000 (JP2, JPX), TIF-G3, TIF-G4, and multi-page PDF.
- Connectivity: USB 3.0 with xDTR3; Gigabit Ethernet with xDTR2.5 for rapid data transfer and workflow integration.
- Operating System Compatibility: Windows 10/11 (64-bit), Windows Server 2022 Standard Edition.
- Dimensions & Weight: 1810 × 540 × 279 mm (71 × 21 × 11 in); 62 kg (137 lbs). Optional stand heights: 922 / 947 / 972 mm.
- Certifications: ENERGY STAR®, RoHS, REACH, cUL, CE, CCC, VCCI compliant.
- Country of Origin: Designed and engineered in Denmark; manufactured in China.
HD Ultra X 6090 Pro Enhancements
- Full Nextimage Repro software licence included
- Optional 22-inch multi-touch monitor (1920 × 1080) with VESA mounting
- Low-stand configuration for production workflows
- Explicit AutoCAD, MicroStation, and ArcGIS compatibility
- Built-in power supply (100 – 240 V, 39 W ready / <1 W sleep / 130 W scan)
Request a Quote for Contex HD Ultra X 6090
Order the HD Ultra X 6090 Today
Take productivity to the next level with the high-speed Contex HD Ultra X 6090. Order yours today, or contact our specialists for professional advice on selecting the ideal model for your scanning operation.
