Crowley C400 Advanced Aperture Card Scanner
The Crowley C400 Advanced is the next generation of aperture card scanners, setting a new benchmark in performance, speed, and image quality. With an upgraded camera system, larger input hopper, and refined internal mechanics, it digitises all 35mm aperture card formats, including those with Hollerith punch data, with outstanding precision.
As the only production aperture card scanner available on the market, the C400 Advanced delivers efficient batch scanning, high-resolution image capture, and reliable operation. Its automatic feed system can handle up to 300 cards unattended, doubling the capacity of previous models, while the enhanced lighting and camera deliver superior clarity for every scan.
Micrographic Engineering Services is an authorised dealer of Crowley’s industry-leading scanning systems in Australia.
Crowley C400 Advanced Aperture Card Scanner
Key Features
Increased Hopper Capacity
Doubled capacity of 300 cards for greater productivity and automation.
Enhanced Camera and Light Source
Provides excellent image quality and clarity for all aperture card types.
Improved Internal Design
Easier serviceability with quick, low-maintenance operation.
Automatic and Manual Scanning Modes
Supports unattended batch scanning or on-demand single-card scanning.
Hollerith Data Reading
Automatically reads punch data to assign drawing sizes and file names.
High-Quality Output
Saves both bitonal and grayscale images from a single scan for maximum flexibility.
Virtual Rescan Feature
Allows users to reprocess images digitally without rescanning cards.
Comprehensive Editing Tools
Includes C400 Advanced software for resizing, enhancement, and image correction.
What’s Included
- Crowley C400 Advanced Aperture Card Scanner unit
- C400 Advanced image editing software
- Power and data cables
- Setup and user documentation
- Manufacturer support and warranty coverage
Why Choose the Crowley C400 Advanced Aperture Card Scanner
- The only production-grade aperture card scanner available today
- Efficiently handles large volumes of aperture cards with minimal supervision
- Produces sharp, accurate, and high-quality images
- Reduces downtime through durable design and low maintenance requirements
- Backed by local service and support from Micrographic Engineering Services
Specifications
- Reduction Ratio: Variable 7.5x to 40x for flexible scaling and image precision.
- Dual-Save Capability: Simultaneous saving of grayscale and bitonal images from a single scan.
- File Formats: Bitonal – TIFF, CALS, PNG, PDF; Grayscale – JPEG, BMP, RAW TIFF, PNG, PDF.
- Resolution: Adjustable from 100 to 600 dpi for detailed image capture.
- Speed: Scans up to 400 cards per hour at 200 dpi, 350 cards at 400 dpi, and 300 cards at 600 dpi.
- Feed System: 300-card automated hopper with manual entry option; automatic Hollerith (IBM, MIL STD 804B) data reading.
- Compatibility: Works with Windows 10 and 11 Pro; compliant with UKCA, CE, FCC, and RoHS standards.
- Dimensions & Power: 560 x 180 x 230 mm; 6.5 kg; 110–240V, 50/60Hz, 65W power consumption.
Request a Quote for Crowley C400 Advanced Aperture Card Scanner
Get the Crowley C400 Advanced Today
Digitise aperture cards faster and more efficiently with the Crowley C400 Advanced.
Order now or contact Micrographic Engineering Services for expert product advice.
