METIS DRS 1622 DCS

The METIS DRS 1622 DCS represents the next evolution in high-end scanning for décor, industrial design, and creative applications. This mid-sized system bridges compact design with the advanced performance of METIS’ flagship scanners. Equipped with a 16K digital imaging sensor and the patented DC Synchrolight lighting system, it delivers outstanding clarity, precision, and colour fidelity across a wide range of materials.


With its large 160 × 100 cm (62.99 × 39.37 in) scanning area, integrated 3D depth mapping, and automated lighting control, the DRS 1622 DCS ensures unmatched productivity and image quality for demanding workflows.


Micrographic Engineering Services is an authorised dealer of METIS scanners in Australia.

OUT OF STOCK

METIS DRS 1622 DCS

/

/

METIS DRS 1622 DCS

Key Features

16K High-Resolution Imaging Sensor

Captures intricate textures and details with up to 1200 PPI at 160 × 34.5 cm and 400 PPI at full format, adjustable from 200 to 2400 PPI for ultimate versatility.

Patented DC Synchrolight LED Lighting System

Dynamically adjusts light intensity and angle in real time for precise illumination and superior reproduction of every material type.

SuperScan Mode and Light Inspector Integration

Records all natural light schematics in a single file, enabling real-time light adjustment and visual re-rendering without rescanning.

Photometric Stereo 3D Mapping

Generates dense and accurate 3D depth data from 2D colour images, ideal for engraving, embossing, digital texturing, and PBR applications.

Scan Merge Technology

Automatically stitches multiple captures to expand scanning capacity beyond the standard 160 × 100 cm format.

Integrated METIS Software Suite

Includes Scan Director, Light Inspector, and Color Profiler software for streamlined acquisition, lighting control, and colour calibration.

What’s Included

  • METIS Scan Director, Light Inspector, and Color Profiler software suite
  • Patented DC Synchrolight LED lighting system
  • 16K high-resolution digital camera
  • SuperScan and Photometric Stereo 3D functionality
  • Optional lighting grids and Scan Merge capability

Why Choose the METIS DRS 1622 DCS Plus

  • Combines compact design with industrial-grade scanning power.
  • Enables 3D, gloss, and PBR data generation for creative and production workflows.
  • Automated operation and intelligent lighting adjustments save time and increase efficiency.
  • Ideal for décor, fine art, cartography, and manufacturing applications.
  • Backed by METIS’ renowned engineering precision and reliability.

Specifications

  1. Scanning Technology: 16K CMOS trilinear imaging system with high dynamic range, low noise, and superior colour fidelity; optical resolution up to 1200 PPI at 160 × 34.5 cm, 400 PPI at full format, software adjustable from 200–2400 PPI.
  2. Scan Format: 160 × 100 cm (62.99 × 39.37 in), expandable using the proprietary Scan Merge tool that automatically stitches multiple captures with pixel-perfect precision.
  3. Image Processing: 16-bit per channel (48-bit) colour depth independent of output format for exceptional tonal accuracy and detail.
  4. Lighting System: Patented DC Synchrolight with 4 (Standard) or 8 (Plus) light sources featuring fully automated, software-controlled intensity and distance adjustment; high CRI, IR/UV-free LEDs.
  5. Acquisition Modes: Supports Scan, SuperScan, Direct SuperScan, and DOF+ modes, with various combinations for enhanced flexibility and workflow efficiency.
  6. Auto-Focus & Original Handling: Automatic adjustment of camera and lighting based on resolution and material thickness; accommodates originals up to 12 cm (4.72 in) thick.
  7. Software Suite: Includes METIS Scan Director, Light Inspector, and Color Profiler, providing integrated control over scanning, lighting, and colour management with ICC profile support.
  8. File Formats: METIS MDC, TIFF (48/24-bit colour, 16/8-bit greyscale), JPEG, and other standard output formats.
  9. Holding Table: 175 × 110 cm (68.90 × 43.31 in) ferromagnetic table with pressure sensors; supports up to 150 kg (330.69 lbs); optional METIS Vacuum Table available.
  10. Dimensions: Length 245 cm, width 190 cm, height 226 cm.
  11. Operating System Compatibility: Windows 10 or 11 Professional (64-bit).


View Brochure & Full Specs

Request a Quote for METIS DRS 1622 DCS

Order the METIS DRS 1622 DCS Today

Experience exceptional colour accuracy, 3D depth mapping, and scanning performance in one powerful system. Order now or contact Micrographic Engineering Services for expert advice on the best METIS solution for your workflow.
