METIS EDS GAMMA

The METIS EDS GAMMA is an advanced A1 desktop planetary scanner that combines outstanding image quality, speed, and usability in a compact design. As the newest member of the METIS EDS (Easy Digital Scanner) family, it introduces innovative features that redefine efficiency and precision in professional scanning.


Designed for versatility, the EDS GAMMA allows users to adjust the scan area and optical resolution according to their needs, offering remarkable flexibility for various types of originals. From large-format maps and drawings to delicate antique books, it delivers sharp, distortion-free images every time.


Micrographic Engineering Services is an authorised dealer of METIS scanners in Australia.

OUT OF STOCK

METIS EDS GAMMA

/

/

METIS EDS GAMMA

Key Features

Innovative V-Table Design

The advanced V-Table accommodates originals of various thicknesses and angles, using shape recognition and curvature correction for distortion-free scanning up to 15 cm thick.

Automatic Shape & Finger Recognition

Smart software detects both page geometry and operator movement, automatically initiating scans once the fingers are recognised.

Automatic Curvature Correction & Finger Removal

Captured images are automatically deskewed and fingers removed, producing clean, professional-quality results every time.

Customisable EDS Lighting

Four independently adjustable LED lamps with 93 CRI provide full control over brightness and angle, ensuring optimal illumination and accurate colour reproduction.

Variable Scan Area & Resolution

Integrated zoom optics and adjustable camera height allow flexible scan sizes beyond A1 format, with resolutions exceeding 800 PPI on smaller documents.

Intuitive & User-Friendly Software

The EDS icon-based interface is simple to operate and touch-screen compatible, streamlining workflows for both novice and professional users.

What’s Included

  • EDS GAMMA Scanner Unit
  • Adjustable V-Table System
  • EDS Software Suite (with shape recognition and curvature correction)
  • Integrated LED Lighting System
  • Power Supply and Connection Cables

Why Choose the METIS EDS GAMMA

  • Combines precision, speed, and ergonomic design in a compact desktop system.
  • Protects fragile materials with a gentle, contactless scanning process.
  • Provides full control over resolution, lighting, and geometry correction.
  • Produces exceptional image clarity that exceeds industry standards.
  • Designed and manufactured by METIS, a global leader in professional digitisation systems.

Specifications

  1. Supported Cameras: FUJI GFX100SII mirrorless 55mm (102 MP), Canon EOS R5 (45 MP), Nikon D850 (45.4 MP) with integrated exposure, colour temperature, and autofocus sensors.
  2. Optical System: Variable camera height and position with integrated zoom optics and motorised focus for optimised scan area and optical resolution (up to ~1000 PPI).
  3. Scan Area: Up to 90 × 60 cm (35.43 × 23.62 in), supporting A1 format (84 × 59.4 cm).
  4. Working Area: Adjustable V-table with two fully independent plates, tiltable and shiftable to accommodate fragile or limited-opening books.
  5. Acquisition Speed: Image capture in under 1 second; full cycle including processing and saving takes approximately 2 seconds.
  6. Lighting System: Professional EDS LED lighting with 3800 lumens and four independently adjustable high-CRI lamps (CRI 93), fully controlled via EDS software.
  7. Dimensions: Base – 90 cm (W) × 85 cm (D) × 138 cm (H); width with open illuminators approximately 140 cm.
  8. Weight: 55 kg (121.25 lb) excluding camera, computer, and monitor.
  9. PC Requirements: Intel i7 processor, 16 GB RAM, 2× USB 2.0 and 2× USB 3.0 ports, Windows 10 Professional 64-bit operating system.


View Brochure & Full Specs

Request a Quote for METIS EDS GAMMA

Bring Precision & Flexibility to Every Scan

Digitise large-format or delicate materials with ease and accuracy. Order now or contact Micrographic Engineering Services for expert advice on the right METIS scanner for your needs.
