Microtek LS-3800

The Microtek LS-3800 is a high-performance large-format flatbed scanner built for precision, versatility, and reliability. With a generous 37” x 24” scanning area, larger than DIN A1, it is ideal for digitising architectural drawings, blueprints, textiles, fine art, maps, and fragile documents. Its colour CCD sensor and 800 dpi optical resolution deliver superior image clarity, while the switchable two-way LED light source ensures balanced lighting across both flat and textured surfaces.


With a 10 mm depth of field, the LS-3800 captures intricate details of thick or uneven materials with exceptional accuracy. Designed for professional environments, it combines user-friendly operation with powerful optional software suites to suit a variety of industry needs.


Micrographic Engineering Services is an authorised dealer of Microtek scanners in Australia.

OUT OF STOCK

Microtek LS-3800

/

/

Microtek LS-3800

Key Features

Flatbed Design for Versatile Scanning

Accommodates a wide range of media, from fragile artworks to textiles, charts, and bound books, without requiring a feeder mechanism.

Switchable Two-Way LED Light Source

Offers flexibility between dual and single light modes; dual mode minimises shadows, while single mode enhances depth and realism.

High Optical Precision with 800 dpi Resolution

Captures fine details and accurate colours for professional-grade results across all document types.

10 mm Depth of Field

Allows scanning of thick or textured items, including oil paintings, relief patterns, and sculptures, with lifelike dimensional detail.

Casters for Easy Mobility

Equipped with four adjustable casters, allowing convenient movement, installation, and repositioning in studio or office spaces.

Optional Software Suites for Specialised Tasks

Compatible with dedicated Microtek software, including ScanWizard Graph, DTG, and Cubi, for applications in design, textiles, and 3D imaging.

What’s Included

  • Switchable two-way LED lighting system
  • Built-in colour CCD sensor
  • Adjustable leveling casters
  • USB connectivity and power cables
  • Optional software packages (ScanWizard Graph, DTG, and Cubi)

Why Choose the LS-3800

  • Large-format scanning area suitable for A1+ originals
  • Captures fine art, textiles, and blueprints with true-to-life accuracy
  • Dual lighting modes adapt to different materials and textures
  • Simple operation with zero warm-up LED lighting
  • Ideal for professional studios, archives, and textile production

Specifications

  1. Scanning Technology: Colour Line CCD sensor with 48-bit input and 24-bit output, delivering crisp, accurate imaging across a large scanning area.
  2. Optical Resolution: 800 dpi optical resolution for high-definition reproduction of fine details, textures, and colour gradients.
  3. Scanning Area: Up to 940 × 610 mm (37” × 24”), exceeding A1 size—ideal for architectural drawings, blueprints, textiles, and fine art.
  4. Light Source: Switchable LED system offering consistent illumination with zero warm-up time and reduced shadows for uneven surfaces.
  5. Depth of Field: Up to 10 mm, enabling clear capture of thick, textured, or uneven originals such as canvases and sculptures.
  6. Scanning Speed: Approximately 30 seconds per A1 colour scan at 200 dpi.
  7. Connectivity: Hi-Speed USB 2.0 interface for stable, fast data transmission.
  8. Supported File Formats: TIFF, BMP, JPEG, JPEG2000, and PDF for flexible file output.
  9. Operating System Compatibility: Windows 7 / 8 / 10 / 11 (x64 & x86).
  10. Software: Includes ScanWizard Graph and optional ScanWizard Cubi for advanced image correction and 3D visual capture.
  11. Power Requirements: AC 100–240 V, 47–63 Hz, maximum 1.7 A input.
  12. Dimensions & Weight: 1330 × 870 × 880 mm (without cover); weight 172 kg (379 lbs).
  13. System Requirements: Intel Core i5 (3.0 GHz or higher), 8 GB RAM or more, CD-ROM drive, Hi-Speed USB port, and 24-bit colour display.
  14. Compliance: EMC Class A certified for professional use.


View Brochure & Full Specs

Request a Quote for Microtek LS-3800

Discover Precision and Flexibility in Every Scan

Digitise your large-format projects with unmatched quality and ease. Order now or contact Micrographic Engineering Services for expert advice on the right Microtek scanner for your needs.
