nextScan FlexView™ Compact Microfilm Digitisation Scanner

The FlexView™ from nextScan is a compact, high-performance microfilm digitisation scanner built for organisations that want full control of their film conversion process. Capable of scanning up to 300 frames per minute, the FlexView allows you to convert, preserve, and access your microfilm collections directly within your facility, on your own schedule and with your own team.


Featuring nextScan’s precision line scan capture technology and proprietary LuminTec™ lighting, it produces true archival-grade digital reproductions from even the most challenging source films. Designed for reliability, portability, and ease of use, FlexView™ bridges the gap between digital viewers and production-level scanners, offering professional results in a small footprint.


Micrographic Engineering Services is an authorised dealer of nextScan’s professional microfilm conversion systems in Australia.

OUT OF STOCK

nextScan FlexView™ Compact Microfilm Digitisation Scanner

Accessories

/

/

nextScan FlexView™ Compact Microfilm Digitisation Scanner

Key Features

Compact Production-Grade Design

Combines the power of an archival film scanner with the convenience of a lightweight, portable design for on-site conversions.

High-Speed Capture Performance

Scans up to 300 images per minute, enabling full roll conversion in as little as 10 minutes.

Guaranteed Image Accuracy

Uses precision line scan technology to capture every frame from top to bottom, ensuring complete and secure data reproduction.

Exceptional Image Quality

LuminTec™ lighting and high-precision optics deliver superior clarity and resolution from all microfilm types.

Optimised Workflow Software

NextStarPLUS® Workflow Software streamlines every stage of scanning — from capture and indexing to auditing and output for maximum productivity.

Flexible Operation

Ideal for both small and large projects, allowing operators to audit one roll while scanning the next.

What’s Included

  • FlexView™ Compact Microfilm Digitisation Scanner
  • Integrated line-scanning camera system
  • NextStarPLUS® Workflow Software Platform
  • PC workstation
  • Optional Digital Storage Server (RSD)

Available Accessories:

  • Pancake Reel Compatibility
  • 3M Cartridge Adapter
  • Splice-Ready Film Handling

Why Choose the FlexView™

  • Delivers true archival-grade microfilm image capture in a compact format
  • Lightweight and portable, suitable for office or production environments
  • Variable scanning speeds up to 300 frames per minute
  • Fully configurable workflow with simultaneous capture, index, and output
  • Backed by nextScan’s best-in-industry warranty and Australian dealer support

Specifications

  1. Scanner Speed (200 DPI, 24x): FlexView 150 – 19:47 minutes per roll; FlexView 300 – 9:53 minutes per roll.
  2. Ribbon Storage Device (RSD): Pre-configured 4 TB, 8 TB, and 12 TB options for simultaneous output and capture.
  3. Operating System: Windows 10 (64-bit) platform for optimal performance and compatibility.
  4. Reduction Ratio & Resolution: Up to 15,500 DPI native optical resolution on film; 640 DPI at 24x and 320 DPI at 48x reduction ratios.
  5. Camera & Lighting System: Proprietary LuminTec™ stroboscopic LED illumination with an 80 mm diffraction-limited Rodagon lens and 8/10/12-bit CCD array (8192-pixel).
  6. Film Compatibility: Supports 16 mm and 35 mm open spool or 3M cartridge films.
  7. Film Types: Compatible with vesicular, blue and black diazo, silver, simplex, duplex, duo, COM, blipped/unblipped, and mixed formats.
  8. File Formats: TIFF Bitonal G3/G4, TIFF Uncompressed, Multi-page TIFF, JPEG, CALS, PDF/A, Searchable PDF (optional), Multi-page PDF, and JPEG 2000.
  9. Physical Characteristics: Height 9", width 17", depth 18"; weight 37 lbs (17 kg).
  10. Warranty: One-year warranty; assembled in the USA.


View Brochure & Full Specs

Request a Quote for nextScan FlexView™ Compact Microfilm Digitisation Scanner

Convert and Preserve with Confidence with FlexView™

Digitise your microfilm archives efficiently and accurately with the nextScan FlexView™ Compact Microfilm Digitisation Scanner. Order now or contact Micrographic Engineering Services for expert advice on selecting the right system.
