SMA Document Scanner DS3X1
The SMA DS3X1 is a premium German-engineered production scanner designed to deliver exceptional performance, durability, and image quality. Compact yet powerful, it combines the advanced features of a high-end production scanner with the cost-efficiency needed for everyday operations.
Capable of 24/7 operation, the DS3X1 is ideal for businesses managing daily workloads from hundreds to tens of thousands of pages. With precision paper handling, intuitive operation, and full compliance with FADGI and ISO standards, this scanner offers consistent, professional results at an accessible price point.
Micrographic Engineering Services is an authorised dealer of SMA’s professional document scanners in Australia.
SMA Document Scanner DS3X1
Key Features
German Engineering Excellence
100% made in Germany, combining reliability, precision, and long-term durability for demanding digitisation environments.
High-Speed Performance
Scans between 100 and 240 pages per minute depending on the model, with optional SlowDown Mode for delicate documents.
Versatile Document Handling
Supports transport widths up to 317.5 mm, with straight-through paper paths and gentle transport for mixed media.
Advanced Usability
Features a large 7" multi-touch panel, intuitive interface, and easy access to all transport areas for quick adjustments and maintenance.
Smart Image Processing
Delivers high-quality scans compliant with FADGI and ISO standards, supported by NoSCRATCH glass guides and HD imprinter options.
Unlimited Daily Throughput
Designed for continuous use, providing high-end scanning capabilities without performance degradation.
What’s Included
- SMA DS3X1 Document Scanner unit
- Power and connectivity cables
- Integrated software suite and drivers (TWAIN, ISIS, WIA)
- User manual and setup documentation
- One-year manufacturer warranty
Why Choose the SMA DS3X1
- Delivers top-tier performance in a compact, affordable design
- Designed for continuous 24/7 operation with gentle document handling
- Complies with FADGI and ISO imaging standards for professional results
- Easy-to-use touchscreen interface for fast setup and operation
- Built with German precision for long-term reliability and efficiency
Specifications
- Scanning Method: CCD line sensor with LED illumination for consistent, high-quality image capture.
- Optical Resolution: 600 dpi optical resolution with selectable output resolutions of 75, 100, 150, 200, 240, 300, 400, and 600 dpi.
- Compression & Colour Depth: CCITT Group IV, JPEG, PDF/R, TIFF, or uncompressed output; 24-bit colour, 8-bit greyscale, and bitonal options.
- Scan Speed: 100–120 sheets per minute (A4 landscape at 300 dpi, depending on model) with optional SlowDown Mode (20/40/70 ppm).
- Document Handling: Supports paper weights from 30 g/m² to 300 g/m²; document width 56–317.5 mm, length up to 1950 mm (LongDoc Mode up to 15.5 m); 50 mm stack height (~500 sheets).
- Image Processing: Bicubic deskew, dynamic binarisation, 3-level gamma correction, colour dropout (up to three areas), ICC profile support, and automatic blank page detection.
- Connectivity & OS: USB 3.0 interface; three USB 2.1 ports for input devices; supports Windows 7/8 (32/64-bit) and Windows 10/11 (64-bit); TWAIN, ISIS (MS61-compatible), and WIA drivers.
- Power & Environmental: 100–240 V, 50/60 Hz, max 200 W; standby <0.5 W; operating temperature 10–35°C; humidity 30–80% (non-condensed).
- Dimensions & Weight: Width 468 mm, depth 910 mm, height 380 mm; weight 50 kg (without options).
- Warranty: 12-month standard warranty; 36-month NoSCRATCH warranty on glass guide.
Request a Quote for SMA Document Scanner DS3X1
Streamline Your Document Workflow with the DS3X1
Achieve high-speed, high-quality scanning with the SMA DS3X1 Document Scanner.
Order now or contact Micrographic Engineering Services for expert advice on selecting the right model for your needs.
