SMA Versascan 36100
The SMA VERSASCAN 36100 redefines large-format digitisation with its extraordinary double A0 scanning capability and an impressive scanning length of 2540 mm. Built for archives, libraries, and industries handling oversized or fragile materials, it combines precision, speed, and reliability. Its innovative Virtual 3D (V3D) technology captures the depth, texture, and reflective qualities of any surface, from textiles to metallic prints, with lifelike accuracy.
The user-friendly design makes scanning as simple as operating a photocopier, while the roll-away mount and optional motorised height adjustment enhance flexibility and ease of use. With its robust construction and advanced imaging features, the VERSASCAN 36100 is the trusted choice of professionals worldwide.
Micrographic Engineering Services is an authorised dealer of SMA scanners in Australia.
SMA Versascan 36100
Key Features
Extended Double A0 Scanning Range
Captures documents up to 914 × 2540 mm (36 × 100 in), making it ideal for very long or extra-large originals.
High Optical Resolution
Delivers a consistent 600 ppi true optical resolution across the full scanning bed for superior detail and clarity.
Virtual 3D (V3D) Technology
Accurately captures surface texture and reflective materials like wood, seals, textiles, and metals for realistic results.
Fast, Bidirectional Scanning
Provides exceptional speed and productivity for large-scale digitisation workflows.
IR & UV-Free LED Illumination
Protects sensitive materials with safe, white LED lighting that eliminates harmful radiation.
Ergonomic Mobility Design
Includes a roll-away mount with fold-up function, with an option for motorised height adjustment to suit operator comfort.
What’s Included
- Roll-away mount with fold-up function
- Integrated white LED lighting (IR & UV free)
- V3D scanning capability with switchable 2D mode
- Batch Scan Wizard software
- IP network interface with individual address assignment
Why Choose the VERSASCAN 36100
- Designed for ultra-large and extra-long originals up to 2A0+ in size.
- Captures 3D surface details beyond traditional flatbed scanning.
- Simplifies operation with intuitive, copier-style functionality.
- Built for archives, museums, and industrial imaging projects.
- Supported by SMA’s proven large-format scanning expertise.
Specifications
- Scanning Technology: Sealed and dust-proof optical system with white LED illumination (IR and UV free, IEC 60825-1 Class 1); optical resolution up to 1200 ppi.
- Scanning Range: Supports documents up to 2540 × 915 mm (100 × 36 in), accommodating oversized originals beyond double A0 format.
- Throughput Speed: Full-colour scans completed in approximately 16 seconds at 300 or 600 ppi across the entire range.
- Colour Depth: 48-bit capture with 24-bit output for colour, and 16-/8-bit output for greyscale images.
- Connectivity: GBit network interface for high-speed data transfer and remote scanner management.
- Image & File Output: Compatible with Batch Scan Wizard software, supporting colour, greyscale, and monochrome imaging workflows.
- Mount & Mobility: Roll-away mount with fold-up function included; optional motorised height adjustment and TV stand for large-format monitor.
- Power & Environment: Operates at +5°C to +40°C, humidity 20–80% (non-condensed); IR/UV-free lighting ensures safe digitisation of sensitive materials.
- Dimensions & Weight: Width 305 cm, depth 120 cm, height 100 cm; weight 150 kg (without PC and monitor).
- Operating Systems: Windows 7/8/10 (64-bit) compatible for seamless workflow integration.
Request a Quote for SMA Versascan 36100
Order the VERSASCAN 36100 Today
Digitise oversized originals with precision and speed using SMA’s double A0 flatbed technology.
Order now or contact Micrographic Engineering Services for expert advice on the best VERSASCAN solution for your application.
