SmartLF SCi 36 (M,C,E)

The Colortrac SmartLF SCi 36 series delivers professional, wide-format scanning performance in a versatile 36-inch design. Ideal for technical drawings, blueprints, GIS maps, and artwork, it combines precision and speed with user-friendly operation. Each model in the range shares the same robust SingleSensor imaging technology and 1200 dpi optical resolution for consistently sharp, accurate results across the full document width.


Available in three models: SCi 36m, SCi 36c, and SCi 36e — the series caters to every level of scanning need. The SCi 36m is built for high-speed monochrome and grayscale work, the SCi 36c adds true 24-bit colour capability, and the SCi 36e enhances colour reproduction further with expanded RGB profiles and faster throughput. Each model can be upgraded, giving you flexibility to grow as your workflow demands evolve.


Micrographic Engineering Services is an authorised dealer of Colortrac scanners in Australia.

OUT OF STOCK

SmartLF SCi 36 (M,C,E)

Model Version

Available Models:

  • SmartLF SCi 36e (Double Speed Colour)
  • SmartLF SCi 36c (Colour)
  • SmartLF SCi 36m (Monochrome)

/

/

SmartLF SCi 36 (M,C,E)

Key Features

SingleSensor Imaging Technology

All models use Colortrac’s one-piece sensor system for superior illumination and edge-to-edge precision, eliminating stitching errors common in staggered-array scanners.

Three Configurations for Different Needs

  • SCi 36m: Optimised for monochrome and grayscale scanning at up to 13 inches per second.
  • SCi 36c: Adds 48-bit colour capture with 24-bit output at up to 6 inches per second.
  • SCi 36e: Expands to Adobe RGB and Device RGB colour profiles with enhanced colour depth and 12 inches per second colour speed.

Upgradeable System Architecture

Future-proof your investment with easy model upgrades—SCi 36m can be upgraded to 36c or 36e, and SCi 36c can be upgraded to 36e.

SmartWorks Software Suite

Includes SmartWorks Touch for straightforward operation and compatibility with SmartWorks Imaging and SmartWorks Pro for advanced editing, batch scanning, and FADGI *** compliance.

SuperSpeed USB 3.0 Interface

Delivers data transfer rates up to 85 MB/sec, supporting full-speed scanning even at higher resolutions.

Dynamic Document Feed System

Active roller control ensures even pressure and accurate feeding of delicate, folded, or uneven documents for optimal image consistency.

What’s Included

  • Colortrac SmartLF SCi 36 scanner (m, c, or e model)
  • Power supply and connection cables
  • USB 3.0 cable
  • SmartWorks Touch software package
  • Calibration target and user documentation

Why Choose the SmartLF SCi 36

  • Available in monochrome, colour, and enhanced colour models
  • Upgradable design lets you expand your scanner’s capabilities later
  • High-speed, high-accuracy imaging with FADGI *** compliance
  • Compatible with SmartWorks Imaging, SmartWorks Pro, and LINK remote app
  • Suitable for engineering, design, GIS, and archive-quality applications

Specifications

  1. Model Options and Upgradeability: Available in three models – SCi 36m (monochrome), SCi 36c (colour), and SCi 36e (enhanced colour). Models can be upgraded ( m → c → e or c → e ) to expand functionality as workflow needs grow.
  2. Optical Resolution: 1200 dpi native optical resolution with linear interpolation from 100 to 9600 dpi in single-step increments for precision scanning.
  3. Maximum Scan and Media Size: Scans up to 36 inches (914 mm) wide; supports media up to 38 inches (965 mm) wide and 2 mm thick.
  4. Imaging Technology: Colortrac SingleSensor system ensures consistent illumination and edge-to-edge accuracy across the entire scanning width.
  5. Colour Performance: SCi 36m captures 16-bit grayscale; SCi 36c and 36e capture 48-bit colour / 16-bit grayscale with 24-bit output. The 36e extends support to Adobe RGB and Device RGB profiles for advanced colour workflows.
  6. Scan Speeds: Monochrome and grayscale at 13 in/sec (200 dpi) for all models; colour at 6 in/sec on SCi 36c and 12 in/sec on SCi 36e.
  7. Interface and Data Transfer: SuperSpeed USB 3.0 connection delivering up to 85 MB/sec throughput; backward-compatible with optimised USB 2.0.
  8. Accuracy and Auto-Sizing: Accuracy of ± 0.1% ± 1 pixel with automatic document width detection and display in mm or inches.
  9. Software and Compatibility: Supplied with SmartWorks Touch; compatible with SmartWorks Imaging and SmartWorks Pro for extended image editing and FADGI *** compliance.
  10. Power and Build: ENERGY STAR® certified external 100–240 V auto-sensing power supply; scanner weighs 24 kg (53 lbs) and measures 45.1 × 6 × 15 in (115 × 15.2 × 38.1 cm).


View Brochure & Full Specs

Request a Quote for SmartLF SCi 36 (M,C,E)

Order the Colortrac SmartLF SCi 36 Series

Select the model that fits your workflow: SCi 36m for mono, SCi 36c for colour, or SCi 36e for enhanced professional imaging. Add to cart today or contact our team for expert advice on the best large-format scanner for your requirements.
