SmartLF SCi 42 (M,C,E)

The Colortrac SmartLF SCi 42 series brings large-format precision and professional-grade speed to your workspace. Built for high-volume environments, it scans architectural plans, engineering drawings, blueprints, and maps with exceptional clarity up to 42 inches wide. The advanced SingleSensor technology delivers seamless, edge-to-edge imaging accuracy, while its SuperSpeed USB 3.0 interface supports faster data transfer and real-time scanning across all models.


Whether your work centres on technical drawings, design projects, or colour-critical imaging, there’s an SCi 42 model to suit your workflow. The SmartLF SCi 42m delivers dependable monochrome and grayscale results, the SmartLF SCi 42c expands functionality with full-colour imaging, and the SmartLF SCi 42e brings professional-grade colour depth with faster output and advanced RGB profiling. With easy upgrade paths between models, your investment continues to grow alongside your business.


Micrographic Engineering Services is an authorised dealer of Colortrac scanners in Australia.

OUT OF STOCK

SmartLF SCi 42 (M,C,E)

Model Version

Available Models:

  • SmartLF SCi 42e (Double Speed Colour)
  • SmartLF SCi 42c (Colour)
  • SmartLF SCi 42m (Monochrome)

/

/

SmartLF SCi 42 (M,C,E)

Key Features

SingleSensor Imaging Technology

Colortrac’s SingleSensor ensures consistent illumination and precise image capture across the entire 42-inch scan width, reducing stitching errors common in staggered-array scanners.

Three Configurations for Versatile Workflows

  • SCi 42m: Monochrome and grayscale scanning at 13 in/sec (200 dpi).
  • SCi 42c: Adds 24-bit colour capture at 6 in/sec (200 dpi).
  • SCi 42e: Delivers extended colour profiles and doubles the colour speed to 12 in/sec.

Upgradeable Performance

Expand your scanner’s capabilities as your business grows—upgrade from m → c → e or c → e to access higher colour performance and advanced imaging control.

FADGI 3-Star Image Quality

Achieve professional-grade results that meet the FADGI *** standard when operating with SmartWorks Imaging software.

SmartWorks Software Suite

Includes SmartWorks Touch for intuitive scanning and copying, with support for SmartWorks Imaging and SmartWorks Pro for advanced image control, batch scanning, and printer integration.

Large Document Staging Platform

Face-up, front-entry design with auto-size detection allows quick loading of maps, drawings, and thick media up to 2 mm.

What’s Included

  • Colortrac SmartLF SCi 42 Scanner (choose from m, c, or e model)
  • Power cable and external power supply
  • USB 3.0 connection cable
  • SmartWorks Touch software
  • Calibration target and user documentation

Why Choose the Colortrac SmartLF SCi 42 Series

  • Available in mono, colour, and enhanced colour models
  • Upgradeable system architecture for future expansion
  • High-speed scanning up to 12 inches per second in colour
  • Compatible with SmartWorks Imaging and LINK remote app
  • ENERGY STAR® certified for energy-efficient operation

Specifications

  1. Model Options and Upgrade Paths: Three models available — SCi 42m (monochrome) , SCi 42c (colour) , and SCi 42e (enhanced colour) . Models can be upgraded ( m → c → e or c → e ) for expanded capability as workflow demands grow.
  2. Optical Resolution: 1200 dpi native resolution with linear interpolation from 100 to 9600 dpi for ultra-fine detail reproduction.
  3. Maximum Scan and Media Size: Scans originals up to 42 inches (106.7 cm) wide; supports media up to 44 inches (111.6 cm) wide and 2 mm thick.
  4. Imaging Technology: SingleSensor system delivers even illumination and consistent accuracy across the entire scanning width.
  5. Colour Performance: SCi 42m handles 16-bit grayscale, SCi 42c adds 48-bit colour / 16-bit grayscale, and SCi 42e extends to Adobe RGB and Device RGB with faster colour throughput.
  6. Scan Speed: 13 in/sec (200 dpi) for mono and grayscale on all models; 6 in/sec colour speed on SCi 42c and 12 in/sec on SCi 42e.
  7. Interface: SuperSpeed USB 3.0 connectivity (up to 85 MB/sec) with optimised USB 2.0 support for reliable data transfer.
  8. Accuracy and Auto Detection: ±0.1% ±1 pixel precision with automatic document width detection in millimetres or inches.
  9. Software Compatibility: Includes SmartWorks Touch; supports SmartWorks Imaging and SmartWorks Pro for professional image processing and FADGI *** compliance.
  10. Power and Build: ENERGY STAR® certified power supply (100–240 V, 50–60 Hz); scanner weight 26.5 kg (58.4 lbs) and dimensions 51.2 × 6.0 × 15 in (130 × 15.2 × 38.1 cm).


View Brochure & Full Specs

Request a Quote for SmartLF SCi 42 (M,C,E)

Order the Colortrac SmartLF SCi 42 Series

Choose the model that best fits your workflow: SCi 42m for mono, SCi 42c for colour, or SCi 42e for enhanced professional imaging. Add to your cart today or contact our team for professional guidance on the ideal Colortrac scanner for your business.
